Mold Transportation With Electric Motor Transfer Cart For Automobile Industry
Remarkable designs and manufactures 15 tons electric transfer carts for a Schneider Electric manufacturer. The function of this trackless transfer carts is to move auto parts weighing more than 15 tons. The drive of these trolleys is electric, using batteries and wireless control. In this case, the handcart tailored for them has two addressable shafts that can pass through very narrow passages.
Previously, customers used diesel forklifts to move molds in the factory, resulting in pollution, noise and different operations to pass through the corridor. This type of diesel forklift needs thorough maintenance to work normally.
Using Remarkable logistics and transportation solutions, customers improve productivity, avoid pollution and require the least maintenance.
The electric trackless transfer Carts Industrial For Port Transportation is mainly applied in working line(ring production line, loop production line, assembly line), metallurgy industry (steel ladle, molten ladle, hot steel slag), warehouse transport, ship industry (maintenance, assemble, container transport), workpiece transport in workshop, lathe transport, steel factory(steel billet, steel plate, steel tube, steel coil, steel pipe, section steel, steel structure), construction(bridge, simple building, concrete, concrete column), petroleum industry(oil pump, sucker rod and parts), energy(polycrystalline silicon, generator, windmill), chemical industry(electrolytic cell, retort etc), railway(rail maintenance, rail welding, train tractor).
Electric Motor Mold Transfer Cart Advantage
1.Automated work(self propelled/steerable)
2. Safe devices are installed in the transfer cart(warning light, e-stop, buffer...)
3. Robust sturdy car frame
4. AC/DC electric engine , diesel engine or pneumatic engine
5. Remote control&hand pendant control make the operation more convenient.
6. The speed can be adjusted.
7. Easy operation and maintenance
8. Famous brand parts, guarantee the quality and prolong the using lifetime
| Technical parameters for trackless electric transfer carts |
| rated load(t) | 5 | 10 | 15 | 20 | 30 | 40 | 50 | 150 |
| impacted rated load(t) | 7.5 | 15 | 22.5 | 30 | 45 | 60 | 75 | 225 |
| structure of frame | steel plates welded, beam structure |
| max. wheel load(t) | 2.8 | 4.3 | 4.8 | 5.6 | 7.7 | 10 | 12 | 27 |
| ground requirement | cement floor | steel plate ground |
| table size(mm) | 3000×2000 | 3600×2000 | 4000×2200 | 4500×2200 | 5000×2200 | 5500×2300 | 6000×2300 | 10000×3000 |
| height of the whole cart(mm) | 450 | 530 | 600 | 600 | 650 | 700 | 700 | 1200 |
| ground clearance(mm) | 50 | 75 |
| wheels base(mm) | 1500 | 1700 | 1800 | 2000 |
| axles distance(mm) | 2500 | 3100 | 3400 | 3900 | 4300 | 4800 | 5200 | 10000 |
| turning radius(mm) | 2501 | 3101 | 3401 | 3901 | 4301 | 4801 | 5201 | 10001 |
| turning type | turning while driving with no stop |
| control method for turning | control button |
| turning structure | mechanical |
| motor power(Kw) | 3.5 | 5 | 6 | 7 | 10 | 12 | 15 | 15 |
| wheel diameter(mm) | Ф300 x 4 | Ф350 x 4 | Ф400 x 4 | Ф400 x 6 | Ф500 x 6 | Ф600 x 8 |
| wheel material | ZG55+hydropur ture |
| running speed(m/min) | 0-15 | 0-12 |
| brake principle | electric magnetic brake |
| operation method | with wire or no wire |
| battery model | D-250 x 24 | D-33 x 24 | D-400 x 24 | D-440 x 24 | D-250 x 36 | D-330 x 36 | D-440 x 36 | D-600 x 36 |
| battery maintenance | free of maintenance |
| charger's installation | installed on cart | split-type |
| charger function | automatic charging |
| radar control | 3-0.3m, automatic stop for obstacles |
| warning equipment | sound and light |
| other functions | turning light, night light and power display |
